HIGH HEAT RESISTANT - MUFFLER SILVER
WILL WITHSTAND TEMPERATURES UP TO - 1200°F
HIGH HEAT RESISTANT powders are ideal for BBQ’s, industrial heaters, chimney stacks, engine casings, engine manifolds, mufflers and light fixtures.
DESCRIPTION
This true high-temperature silicone system was developed
from a proprietary blend of resins and pigments to provide
service up to 1200°F (649°C). It is designed to be a smooth
coating for steel substrates.
Product Benefits
• Enhanced charging and handling characteristics
• Thinner film builds
• Provides excellent flow and leveling over a wide
range of film thickness
• Great performance at 1000°F (538°C)
• Excellent UV resistance for outdoor use
• Passed the full battery of corrosion performance
tests for automotive applications
• Designed to be more compatible and to reduce
cross contamination with other coatings
SPECIFICATIONS
Cure cycle
20 minutes at 375°F(191°C)
15 minutes at 400°F(204°C)
10 minutes at 425°F(218°C)
5 minutes at 450°F(232°C)
Specific Gravity 1.73 +\-0.05
Theoretical coverage for 1 mil. 112 ft² per pound
Film builds between. 0.80 and 2.50 mils
Recommended at 1.60 mils
Heavier film builds are not recommended.
TYPICAL PROPERTIES
Adhesion(ASTM D3359) ..............................................5B
Gloss at 60°(ASTM D523)..................................1.0 – 4.0
Impact Resistance(ASTM D2794-90)...............120D/60R
Pencil Hardness(ASTM D3363) >2H
PERFORMANCE TESTING
Continuous testing at 1000°F (538°C) shows thIs product
retains gloss, color and physical integrity at this service
temperature. Testing indicates good film integrity after
limited exposure to temperature at 1400°F(760°C). This
formula has tested to the specifications of automotive and
other equipment manufacturers
